LS Central POS Setup Guide for Beginners (Step by Step, 2026)

If you are new to LS Central and need to get a till (POS) up and running, the setup can feel confusing at first. There are stores, terminals, and five different profiles – and they all need to fit together in the right order. The good news? Once you understand the order, it is actually simple.

In this guide, we will set up an LS Central POS from scratch, step by step, in plain English. By the end, you will have a working terminal that can ring up a sale. Let’s get started.

The Big Picture : How LS Central POS Fits Together

Before clicking anything, it helps to see how the pieces connect. Think of it like a shop:

• Store = your physical shop location (it holds prices, tax, and rules)
• POS Terminal = a single till inside that store
• POS Profiles = the settings that control how each till looks and behaves
• Hardware Station = the bridge that connects the till to real devices like printers and cash drawers
• Staff = the people who log in and sell

The setup order matters. You create the Store first, then the Terminal inside it, then assign Profiles, then connect Hardware, then add Staff. Follow that order and everything clicks into place.

Before You Start – Checklist

Make sure you have these ready:

• ✅ LS Central installed and a working Business Central environment (LS Central runs on top of BC)
• ✅ Replication / initial setup done — if this is a head-office-to-store setup, base data should be in place
• ✅ Items and prices created — you need at least a few items to sell
• ✅ Tax / VAT posting setup done — so sales post correctly
• ✅ Hardware ready (optional for a test) — printer, cash drawer, scanner, and a PC to run the Hardware Station

Step 1 : Create a Store

The Store is the foundation. Everything else attaches to it.

1. In LS Central, press Alt + Q and search for “Stores”
2. Click New to create a store
3. Enter a Store No. and Name (for example, S0001 – Main Shop)
4. Fill in the address, currency, and tax/VAT details
5. On the relevant FastTabs, set the price and posting settings the store should use
6. Save the store card

You can leave the profile fields on the store blank for now — we will cover what they do in Step 3.

Step 2 : Create a POS Terminal

A POS Terminal is one till inside your store. A store can have many terminals.

1. Press Alt + Q and search for “POS Terminals”
2. Click New
3. Enter a terminal number (for example, POS001)
4. In the Store No. field, link it to the store you just created
5. Confirm the terminal is set as active
6. Save the terminal card

Step 3 : Understand the 5 POS Profiles

This is the part that confuses beginners most, so let’s make it simple. LS Central uses five profiles to control how a POS looks and works. Each one handles a different job:

The Golden Rule of Profiles

Only one profile of each type can be active on a POS at a time. You can assign profiles at the Store level (applies to all terminals) or the Terminal level (applies to just that till).

How to Assign Profiles

1. Open your Store card (or POS Terminal card for a single till)
2. Find the profile fields (Hardware, Interface, Menu, Style, Functionality)
3. Pick a profile for each, or leave blank to use ##DEFAULT
4. Save

Step 4 : Set Up the Hardware Profile & Hardware Station

The Hardware Station is a small service that runs on the POS computer and connects LS Central to real devices like printers and cash drawers. Here is the simple version of setting it up.

Install the Hardware Station

1. Install the LS Hardware Station on the POS computer (via the LS Central Client Components installer or the Update Service)
2. Start the LS Hardware Station service — it must be started after install
3. Open the Management Portal in a browser at localhost:8088 and load your devices (printer, scanner, cash drawer, etc.)

Connect the Hardware Station to a Hardware Profile

1. In LS Central, press Alt + Q and search for “POS Hardware Profiles”
2. Open an existing profile or click New
3. On the LS Hardware Station FastTab, tick Sync with LS Hardware Station
4. Enter the correct Hardware Station Host (URL or IP address). The default port is 8082
5. Click Detect Hardware — all devices loaded in the Management Portal are pulled into the profile automatically
6. Save the profile and make sure it is assigned to your Store or Terminal

Step 5 – Set Up Staff and Login

Staff are the people who log in to the POS and make sales. Each gets a Staff ID and a login.

1. Press Alt + Q and search for “POS Staff” (or “Retail Users”)
2. Click New and create a Staff ID with a name
3. Set a password or login code for the staff member
4. Assign the right permissions so they can only do what their role allows (cashier, manager, etc.)
5. Link them to the store(s) they work in

Step 6 : Run the POS and Make Your First Sale

Now the exciting part — opening the till and ringing a sale.

1. Launch the LS Central POS (Web POS or Windows POS) on the terminal
2. If a green connection banner appears, your Hardware Station is connected correctly ✅
3. Log in with your Staff ID and password
4. Open the day / open the till if your setup requires it
5. Scan or select an item — it appears on the sale
6. Press Pay, choose a payment method (like Cash), and complete the sale
7. The receipt prints (or shows on screen if no printer) — you just made your first sale! 🎉

Common Mistakes to Avoid

• ❌ Setting up out of order — always Store → Terminal → Profiles → Hardware → Staff.
• ❌ Forgetting to assign a payment method — the till opens but can’t take payment. Check the Menu Profile’s payment menu.
• ❌ Firewall blocking port 8082 — the number one hardware connection failure.
• ❌ Over-customizing before testing — get a sale working on default profiles first, then refine.
• ❌ Skipping the test sale — never go live without ringing at least one real transaction.
• ❌ Wrong profile level — remember Terminal-level profiles override Store-level ones.

FAQ : LS Central POS Setup

What are the five POS profiles in LS Central?

They are Hardware, Interface, Menu, Style, and Functionality. Hardware controls devices, Interface controls the screen layout, Menu controls buttons and payment menus, Style controls colors and fonts, and Functionality controls behavior rules like rounding and receipts. Only one of each type is active on a POS at a time.

What is the ##DEFAULT profile?

If you leave a profile field empty on both the Store and the Terminal, LS Central automatically uses the ##DEFAULT profile for that type. It is the fallback setup, which is why a fresh POS often works straight away. You only assign a specific profile when you want something different from the default.

Do I need real hardware to set up an LS Central POS?

No. You can build a store, terminal, and profiles and ring a test sale using LS Central Demo Data without any printer or cash drawer attached. Real hardware is only needed when you connect the Hardware Station for a live store.

What is the LS Hardware Station?

It is a small service that runs on the POS computer and acts as the bridge between LS Central and physical devices like printers, scanners, cash drawers, and card readers. You sync it to a Hardware Profile and use Detect Hardware to pull in your devices.

Why won’t my POS connect to the Hardware Station?

The most common cause is the Hardware Station port (default 8082) being blocked by the firewall on the POS computer. Open that port and confirm the Hardware Station Host URL is correct. If using HTTPS, make sure a valid SSL certificate is in place.

Can profiles be set at the store level or the terminal level?

Both. A profile set on the Store applies to all terminals in that store. A profile set on a Terminal applies only to that till and overrides the store-level setting. Leaving both empty uses the ##DEFAULT profile.

Can one staff member work in multiple stores?

Yes. A Staff ID can log into different stores, and you can set it up so they get different profiles per store. This is useful for staff who move between branches.

What’s the difference between Web POS and Windows POS?

Both run the LS Central POS, but they support hardware differently. The Web POS supports cash drawer, scanner, line display, printer, and EFT through the LS Hardware Station, while the Windows POS supports EFT and printing through the Hardware Station. Choose based on your hardware and deployment model.

Final Thoughts

Setting up the POS in LS Central looks complicated, but it follows a simple, repeatable order: build the Store, add the Terminal, assign the five Profiles, connect the Hardware Station, set up Staff, and run a test sale. Start with the default profiles, get one sale working, and then customize from there.

Once you have done it once, every future terminal takes minutes. Build your first POS today using Demo Data, ring a test sale, and you will understand the whole flow far better than reading about it.

Stay tuned to NavisionPlanet for more simple, step-by-step LS Central and Business Central guides drawn from real store implementations.
